High Torque 400KG/CM Large Servo 24V Power Supply Precision Servo for UAV ROBOT
$ 70.24
Description
Power Supply Precision Servo Features: * Applicable to servo controllers, model airplane remote controllers * Alloy gear high torque motor * Ultra-lightweight aluminum alloy gearbox * Easy to install, durable, reliable, stable and practical to use Applications: * Large robots, mechanical arm power joints * Industrial robot automation * Precise control of valve angle *Large camera PTZ * Large remote-control car models, remote control ship models Technical Parameters: - Rated voltage: DC 24V (12V-24V can work, 12V torque and speed are halved) - No-load current: <500MA (load current 5-10A, it is recommended to use 10A or more than 10A switching power supply or battery, the greater the power supply current output capacity, the better) - Limit angle: 1200-1700US: about 90 degrees; 500-2500US: about 288 degrees (Pulse width determines the angle. If you need other angles, please increase or decrease pulse width by yourself, the maximum is about 288 degrees) - Control mode: 1.0-2.0 MS pulse: suitable for model airplane remote control receiver control; 0.5-2.5 MS pulse: suitable for multi-channel steering gear controller control (pulse frequency: 50-333HZ) - Materials: * Gears and shafts: alloy steel, hardened steel, aluminum alloy; * Shell: aluminum alloy - Servo weight: about 880g - Speed: 0.5S/60° (equivalent to 20RPM) - Mechanical life: >300,000 times (370 hours)/(30KG/CM) - Torque limit: 400KG/CM (Broken gear load, it is not recommended to work at this torque) - Starting torque: 380KG/CM (short-time work) - Conventional torque: 140KG/CM (can work for a long time) Package Included: - 1 x Set of Servo Wiring Video: v.youku.com/v_show/id_XNDg1NzA3MDEwOA==.html Video For Demo: v.youku.com/v_show/id_XNDUyNjE3OTE4NA==.html?spm=a2h3j.8428770.3416059.1 On Jul 4, 2022 at 19:12:23 PDT, seller added the following information:
